Touring bus 16 Vinh PhucSPECIFICATIONS OF TRANSIT 16 DIESEL ENGINE
Size and weight
16-seat Ford Transit LSX
Length x Width x Height 5780 x 2000 x 2360
Wheelbase 3750 x 3750
Front wheel track 1740 x 1740
Rear wheel track 1704 x 1704
Ground clearance 165 x 165
Total weight 3730 x 3730
Minimum rotation radius of 6.65 x 6.65
No-load weight 455 x 2455
16-seat Ford Transit engine SLS
Engine. 2.4L - TDCi Turbo Diesel engine, dual camshafts with intake air cooling
Type 4 cylinders in line
Cylinder capacity (cc) 2402
Cylinder diameter x Stroke stroke (mm)
89.9 x 94.6 x 89.9 x 94.6
Max power (HP / rpm) 138/3500
Maximum torque (Nm / rev / min) 375/2000
Gearbox 6-speed manual clutch
Dried friction disc, driven by hydraulic
Suspension system, 16-seat Ford Transit LSX
Front, independent suspension using torsion springs and hydraulic dampers
After, Dependent suspension uses leaf tweezers with hydraulic damper
Brake system. 16-seat Ford Transit LSX
Front and rear disc brakes
Anti-lock braking system (ABS)
Hydraulic power steering
Main equipment
16-seat Ford Transit LSX
Airbags for the driver
Steps to wipe the front windshield
Lock the bonnet
Cast Steel Lazang
Passenger glass door
Block not open
Car interior ribs
Power steering window and auxiliary steering
Electric control rearview mirror
Central electric door lock
Mudguard before
Fog lights
High mounted rear brake light
Leather seat material
Safety belts fitted to all seats
Steps up and down sliding doors
Support handle up and down
Remote control door lock
Automatic door up and down
The rows of seats (2,3,4) recline
6-way adjustable driver's seat with armrest
Air conditioning 2 indoor units to each seat
Sound system. AM / FM, 1 disc CD, 4 speakers
